Ranges: 500W, 600W, 800W, 1000W, 1500W
Installing the Dimmer:
Ensure that the power is off, remove the existing light switch, taking note of the existing connections.
Connect the live wire directly to the red wire of the dimmer module, do not connect via a switch, as the dimmer has a built in switch. Connect the load to the yellow wire of the dimmer module.
Light dimmers as with all electrical appliances should be installed by suitably qualified personnel.
Ensure you have the correct dimmer before installation.
Calculate the load, by adding up the wattage of all the lights to be dimmed.
If the lights are of the low voltage type, do not exceed the inductive rating of the dimmer, this is the lowest rating of the dimmer, usually about 25% less than the resistive rating.
